A32pro (MADI Multimode) SPECIFICATIONS

■MADI I/O (AES10)
Dual SFP Slots for MADI: Multimode SFP module as
default configuration, optional second SFP module optional
• 64 channels @32kHz, 44.1kHz, 48kHz
• 32 channels @64kHz, 88.2kHz, 96kHz
• 32 channels @128kHz, 176.4kHz, 192kHz*
 * both MADI ports are used to achieve full 32+32 channel transmission
Support of MIDI over MADI.

Latency: 3 samples

Redundancy: Automatic switching between optical <-> coax MADI when signal lost.

■Analog Inputs (A/D)
32Bit ESS A/D Converter
4 x DSub25  (Tascam format)
• Digital gain: +20dBu … -8 dBu, 1dB steps
OpAmps : OPA1604 / OPA1664
Level indicator : TFT screen, 28 levels

■Analog Outputs (D/A)
32 Bit ESS D/A Converter
4 x DSub25  (Tascam format)
• Digital gain: +20dBu … -8dBu, 1dB steps
OpAmps : OPA1604 / OPA1664
Level indicator : TFT screen, 28 levels

■Headphones Out
• 2 x ¼” (6.3mm) TRS jack, stereo with HQ amp section and dedicated DAC path.
• Provides two independent stereo channels.
• Selectable mono/stereo or M/S of all inputs and outputs.
• Digitally controlled volume level.

■ADAT I/O
4+4 optical interfaces (8 channels each with 48 kHz)
• 32 channels @32kHz, 44.1kHz, 48kHz
• 16 channels @64kHz, 88.2kHz, 96kHz
• 08 channels @128kHz, 176.4kHz, 192kHz
Latency: 3 samples

■GPIO Port
• 4x General Purpose Inputs for switching Presets #1-4.
• 4x General Purpose Outputs for monitoring Lock/Power/MADI/Temp alerts.

■MIDI I/O
• 2 x 1/8″ (3.5mm) TRS connector for remote control
• Conversion MIDI <> MIDI-over-MADI possible
• MIDI 2.0 pinout

■Wordclock I/O
• BNC: 1 x input, 1 x output
• Input 75 Ohm Termination switchable by menu button

■Power Supply
12V, 3A
• 2 x input jacks with screw lock for redundant power.
• Input monitoring, warning on screen when PSU input fails
• Internal self-resettable polyfuse
• 1 x Power Supply included, second PSU optional available

■USB Port
1 x USB 2.0 for Remote/Updates

■Dimensions
• 1RU, fanless design
• Dimensions net: 25,3 x 44,4 x 4,4cm (DxWxH)
• Dimensions full: 29 x 48,3 x 4,4cm (DxWxH)
including connectors, knobs and rack ears
■Weight　：　7,72lbs (3,5kg)
■Ambient temperature　：　41°F up to 113°F (+5°C up to +45°C)
